Evo Line Piston Pumps
PA32 - Evo Line
The PA32 of the Evo Line is designed with a green approach to reduce environmental impact, ensuring energy efficiency and sustainability in liquid processing.
PA32 - Evo Line
General Features
Technical Features
The PA32 Evo Line piston pump is designed according to EU safety regulations (EC directives) and in compliance with standard certifications and guidelines: cGMP, MOCA, FDA, 3-A, ATEX and EHEDG.
The PA32 Evo Line piston pump is made for industrial use with a maximum capacity of 8,000 l/h, is robust and reliable. It can install a maximum power of 30 kW. Equipped with forged one-piece compression head made of Duplex SAF2205.
Power: 30 KW
Pressure: 600 bar
Capacity: 8000 l/h
Maximum Capacity (l/h) Pressure (bar)
General Features
No. of pistons:
3
Stroke (mm):
70
Weight (kg):
1,400
Water consumption (l/h):
90
Amount of lubricating oil (kg):
10.5
Product input/output connections:
Welding flange Øe58 Øi52.5 / Øe33.8 Øi25
Maximum installable power (kW):
30
Plus
Hygienic design in accordance with MOCA guidelines
Poppet valves for viscous and abrasive products
Direct drive system with integrated reducer with belts and pulleys
Easy maintenance
Easy-to-open side panels that can be opened individually
Low noise
Areas of application
